EFA30250NA0485D Ring Mount Axial Fan Sucker
Ref: 173005
The EFA30250NA0485D is a electronically commutated (230V 50Hz) sucker ECM (2200rpm) ring mount Assembly. 4 mountings on ring mount (236mm PCD) and supplied with flying leads. An Elco manufactured fan assembly offering superb build quality.
- Blade Diameter : 200mm
- Supply/Voltage : Electronically Commutated (230V, 50Hz)
- Nominal Run Speed (RPM) : ECM (1400-2200rpm)
- Part Number : EFA30250NA0485D
- Connection Type : Flying Leads
- Blade Pitch : 30
- Airflow Direction : Sucker
- Specific Mounting Details : 4 Mountings on Ring mount (236mm PCD)
£56.36 + VAT
Ordering is only available to Trade Customers
Specification for: EFA30250NA0485D Ring Mount Axial Fan Sucker
| Airflow Direction | Sucker |
| Blade Diameter | 200mm |
| Blade Pitch | 30 |
| Brand | Remco |
| Connection Type | Flying Leads |
| Hub Type | Integrated |
| Insulation Class | Class B (130°C) |
| IP Rating | IP65 |
| Nominal Run Speed (RPM) | ECM (1400-2200rpm) |
| Part Number | EFA30250NA0485D |
| Specific Mounting Details | 4 Mountings on Ring mount (236mm PCD) |
| Supply/Voltage | Electronically Commutated (230V 50Hz) |
The EFA30250NA0485D is a electronically commutated (230V 50Hz) sucker ECM (2200rpm) ring mount Assembly. 4 mountings on ring mount (236mm PCD) and supplied with flying leads. An Elco manufactured fan assembly offering superb build quality. The EFA30250NA0485D is a electronically commutated (230V 50Hz) sucker ECM (2200rpm) ring mount Assembly. 4 mountings on ring mount (236mm PCD) and supplied with flying leads. An Elco manufactured fan assembly offering superb build quality.
