MS34TB-T Cubigel Compressor 1 5/8 Hp
Ref: 144204
- Refrigerant : R404a-R507
- Displacement : 34.4
- Displacement : 34.42 cm3
- Application : HMBP
- Supply : 220-240/1/50
- Power : 1 5/8 Hp
- Height : 276 mm
- Displacement: 34.42 cm3
- Power: 1 5/8 Hp
- Refrigerant: R404a-R507
- Application: HBP
- Height: 276 mm
Price only available to Trade - LOGIN HERE
Ordering is only available to Trade Customers
| Weight | 22.21 kg |
|---|---|
| Dimensions | 165 × 219 × 276 cm |
| Application | |
| Brand | |
| cc range | |
| Displacement | |
| Power | |
| Refrigerant |
Specification for: MS34TB-T Cubigel Compressor 1 5/8 Hp
| Ampere | 11.5 |
| Application | HMBP |
| Brand | Cubigel |
| Depth | 165 mm |
| Displacement | 34.42 cm3 |
| Displacement cm3 | 34.4 |
| Electric diagram | CSR |
| Expansion Device | C-V |
| Height | 276 mm |
| LRA | 41.0 |
| Model | MS34TB |
| Motor powerHP | 1.5 |
| Motor Type | CSR |
| Power | 1 5/8 Hp |
| Power supplyVolt/Ph/Hz | 220-240/1/50 |
| Refrigerant | R404a-R507 |
| Test Conditions | CECOMAF EN12900 |
| W Cooling Capacity @ -5 Evap | 2935 |
| W Cooling Capacity @ +5 Evap | 4231 |
| W Cooling Capacity @ 0 Evap | 3556 |
| W Cooling Capacity @ -10°C Evap | 2370 |
| Watt | 2300 |
| Weight | 22.21 Kg |
| Width | 219 mm |
